| ロードセル: | 5KNまたは1トンと2トンのオプション | 力解像度: | 1/200000 |
|---|---|---|---|
| 力の精度: | ≤0.5％ | 変位解像度: | 1/1000 |
| 変位精度: | ≤0.5％ | 速度範囲: | 0.01～500mm/分または1000mm/分 |
| 抗張打撃: | 800mm;1000mm;1200mm | 試験幅: | 380mm |
| 機械のサイズ: | 80*55*220cm(長さ*幅*高さ) | 機械重量: | 約250kg |
| 電源: | 220V | 消費電力: | 約2kW |
| 伸び計の分解能: | 1/1000 | 伸び計の精度: | ≤0.5％ |
| ユニット: | Kg、N、LB、TON、交換可能 | ||
| ハイライト: | 5KN Load Cell Testing Machine,1/200000 Force Resolution Testing Machine,≤0.5% Accuracy Flexural Strength Tester |
||
| Parameter | Measurement Capability |
|---|---|
| Tensile stress | Tensile strength |
| Rate of elongation at break | Fixed stress |
| Rate of stress at break | Tear strength |
| Value of force at any point | Rate of elongation at any point |
| Stress strength | Pull-out strength |
| Force of adhesion | Value of peak |
| Parameter | Specification |
|---|---|
| Model | Three Point Bending Flexural Strength Testing Machine |
| Load Cell | 5KN or 1ton/2ton options |
| Force Resolution | 1/200,000 |
| Force Accuracy | ≤0.5% |
| Power Magnification | 7 automatic switching |
| Displacement Resolution | 1/1,000 |
| Displacement Accuracy | ≤0.5% |
| Extensometer Resolution | 1/1,000 |
| Extensometer Accuracy | ≤0.5% |
| Speed Range | 0.01-500mm/min or 1000mm/min (customizable) |
| Effective Tensile Stroke | 800mm, 1000mm, 1200mm (customizable) |
| Testing Width | 380mm (expandable) |
| Power Supply | 220V |
| Power Consumption | ~2KW (varies by motor) |
| Dimensions (L×W×H) | ~80×55×220cm |
| Weight | ~250kg |
| Units | Kg, N, LB, TON (interchangeable) |
